| Projector type | LCD projector |
|---|
| Display method | Transparent LCD panel (x 3, R/G/B) |
|---|
| Display Device -> Panel size | 16.3 mm (0.64 in) diagonal (16:10 aspect ratio) |
|---|
| Display Device -> Drive method | Active matrix method |
|---|
| Display Device -> Number of pixels | 2,304,000 (1920 x 1200 pixels) |
|---|
| Light source | Laser diodes |
|---|
| Light output *1 | 5,200 lm |
|---|
| Light output (ANSI) | 5,200 lm |
|---|
| Time until light output declines to 50 % -> NORMAL *3 | 20,000 hours [NORMAL] |
|---|
| Time until light output declines to 50 % -> ECO *3 | 24,000 hours [ECO] |
|---|
| Time until light output declines to 50 % -> QUIET *6 | 20,000 hours [QUIET] |
|---|
| Resolution | WUXGA (1920 x 1200 pixels) |
|---|
| Contrast Ratio (typ.) *1 | 3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1].) |
|---|
| Screen size (diagonal) | 2.03–3.05 m (80–120 in) (16:10 aspect ratio) |
|---|
| Center-to-corner zone ratio *1 | 85% |
|---|
| Lens | Fixed zoom, powered focus lens, F = 1.7, f = 2.81 mm, throw ratio: 0.235:1 (16:10 aspect ratio)(Projection distance: 1 cm [1/3 in] for 80-inch image) |
|---|
| Digital Zoom Extender *5 | Throw ratio 0.235–0.288:1*5 (16:10 aspect ratio) (Corresponding value) |
|---|
| Keystone correction range | Vertical: ±3 °, Horizontal: ±3 ° |
|---|
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
|---|
| Terminals -> HDMI™ IN | HDMITM 19-pin x 2 (Compatible with HDCP 1.4, Deep Color, 4K/30p*6 signal input), CEC supported*7 |
|---|
| Terminals -> HDMI™ OUT | HDMITM 19-pin x 1 (Compatible with HDCP 1.4, Deep Color, 4K/30p*6 signal output) |
|---|
| Terminals -> COMPUTER IN（D-SUB 15pin） | D-sub 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
|---|
| Terminals -> AUDIO IN(M3 Stereo Mini Jack) | M3 stereo mini-jack x 1 |
|---|
| Terminals -> AUDIO OUT(M3 Stereo Mini Jack) | M3 stereo mini-jack x 1 |
|---|
| Terminals -> SERIAL IN | D-sub 9-pin (female) x 1 for computer control (RS-232C compliant) |
|---|
| Terminals -> DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseTTM compliant), 100Base-TX (Compatible with PJLinkTM [Class 2], HDCP, Deep Color, 4K/30p*6 signal input) |
|---|
| Terminals -> LAN | RJ-45 x 1 for network control, 10Base-T, 100Base-TX, compatible with PJLinkTM [Class 2] |
|---|
| Terminals -> USB TYPE A | USB connector (Type A) x 1 for Memory Viewer function, optional AJ-WM50 Series Wireless Module,power supply (DC 5 V, maximum 2 A) |
|---|
| Protocol versions | IPv4, IPv6*8 |
|---|
| Power supply | AC 100–240 V, 50/60 Hz |
|---|
| Maximum power consumption | 325 W (3.4–1.4 A) (330 VA) (Power consumption is 310 W at AC 200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Normal | [NORMAL]290 W (AC 100–120 V), 280 W (AC 200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Eco | [ECO]215 W (AC 100–120 V), 205 W (AC 200–240 V) |
|---|
| On-mode power consumption(Operating mode) -> Quiet *8 | [QUIET]210 W (AC 100–120 V), 200 W (AC 200–240 V) |
|---|
| Built-in speaker | 10 W monaural |
|---|
| Cabinet materials | Molded plastic |
|---|
| Filter | Included |
|---|
| Estimated filter maintenance cycle | Approx. 20,000 hours |
|---|
| Operation noise -> Normal *1 | 34 dB [NORMAL] |
|---|
| Operation noise -> Eco *3 | 34 dB [ECO] |
|---|
| Operation noise -> Quiet *1 | 25 dB [QUIET] |
|---|
| Dimensions (W x H x D) | 495 mm x 160 mm x 421 mm (19 1/2˝ x 6 19/64˝ x 16 37/64˝) (excluding feet and protrusions),495 mm x 176 mm x 421 mm (19 1/2˝ x 6 15/16˝ x 16 37/64˝) (with feet at shortest position) |
|---|
| Dimensions (W x H x D) -> Width (not including protruding parts) | 495 mm (19 1/2˝) |
|---|
| Dimensions -> Width (including protruding parts) | 495 mm (19 1/2˝) |
|---|
| Dimensions -> Height (not including protruding parts) | 160 mm (6 19/64˝) |
|---|
| Dimensions -> Height (including protruding parts) | 176 mm (6 15/16˝) |
|---|
| Dimensions -> Depth (not including protruding parts) | 421 mm (16 37/64˝) |
|---|
| Dimensions -> Depth (including lens) | 421 mm (16 37/64˝) |
|---|
| Weight *7 | Approx. 9.5 kg (20.9 lbs) |
|---|
| Operating environment -> Operating temperature *8 *9 | 0–45 °C (32–113 °F) |
|---|
| Operating Environment -> Operating humidity (No condensation) | 20–80 % (no condensation) |
|---|
| Applicable software | Multi Monitoring & Control Software, Logo Transfer Software, Projector Network Setup Software,Presenter Light Software for Windows®*13, Wireless Projector App for iOS/AndroidTM*14 |
|---|
| Control function via LAN | PJLinkTM [Class 2], Crestron ConnectedTM, AMX Device Discovery |
|---|
| Footnote Description | - When [PICTURE MODE] is set to [DYNAMIC], [LIGHT POWER] is set to [NORMAL], and [SYSTEM DAYLIGHT VIEW] is set to [OFF].
- Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped.
- Measurement, measuring conditions, and method of notation all comply with American National Standards Institute standards. Value is the average of all products when shipped.
- Around this time, light output will have decreased to approximately 50 % of its original level ([PICTURE MODE]: [DYNAMIC], [DYNAMIC CONTRAST] set to [2], temperature 30 °C (86 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of particulate matter). Estimated time until light output declines to 50 % varies depending on environment.
- Resolution decreases when using Digital Zoom Extender. Some screen-correction functions are not available when using this function, and range of corner adjustment is limited.
- When Digital Zoom Extender is set to 80 %.
- Supports signals up to 4K/30p. A signal with different resolution is converted to the number of display dots (1920 x 1200 dots).
- Depending on the connected CEC command-compatible device, the link control may not operate normally.
- Main version of the firmware must be 2.00 or higher. Optional wireless module AJ-WM50 does not support IPv6.
- Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft).
- Filter cleaning cycle varies depending on environment. Filter can be washed and reused up to two times. Filter cleaning cycle: 20,000 hours (under dust conditions of 0.08 mg/m3), 10,000 hours (under dust conditions of 0.15 mg/m3).
- Average value. May differ depending on the actual unit.
- Light output is limited at operating temperatures higher than 30 °C (86 °F), and projectors cannot be operated at altitudes higher than 2,700 m (8,858 ft) above sea level. When optional AJ-WM50 Series wireless module is attached, operating temperature range becomes 0–40 °C (32–104 °F).
- When using Presenter Light Software, images are projected with 1280 x 800 dots or 1024 x 768 dots onto the screen. Also, your PC display resolution may be forcibly changed, and audio playback disrupted or become noisy, while images and sound are being transmitted.
- When using the Wireless Projector app, display resolution differs depending on your iOS/Android™ device and the display device. The maximum supported display resolution is WXGA (1280 x 800).
|
|---|
| Body Colour | Black/White |
|---|
| Gross Dimensions (W x H x D in mm) | CMZ50U/CMZ50EJ/CMZ50BU/CMZ50BEJ: 647 x 512 x x270 mm
CMZ50/CMZ50B: 637 x 502 x 256 mm |
|---|
| Gross Weight (Kg) | CMZ50EJ/CMZ50BEJ: 13.7 kg(30.2 lbs)
CMZ50U/CMZ50BU: 13.5 kg(29.8 lbs)
CMZ50/CMZ50B: 12.5 kg(27.6 lbs) |
|---|
| NFC | https://docs.connect.panasonic.com/projector/products/smartpjcontrol/regional.html#regional |
|---|
| EAN | CMZ50: 5025232944088
CMZ50EJ: 5025232944095
CMZ50B: 5025232944101
CMZ50BEJ: 5025232944118 |
|---|
